旋轉供料器作為物料輸送系統的關鍵設備，氣路的設置是保障其高效運行的核心設計，主要服務于密封防護、物料調控與設備保護三大功能。在粉體、顆粒狀物料的連續輸送場景中，氣路系統通過氣流的精準控制，可使設備漏料率降低至 0.5% 以下，同時延長易損件壽命 30% 以上，其設計邏輯與物料特性、工況壓力及輸送環境密切相關。

　　As a key equipment of the material conveying system, the setting of the air path is the core design to ensure its efficient operation, mainly serving the three functions of sealing protection, material regulation, and equipment protection. In the continuous conveying scenario of powder and granular materials, the pneumatic system can reduce the equipment leakage rate to below 0.5% and extend the service life of vulnerable parts by more than 30% through precise control of airflow. Its design logic is closely related to material characteristics, working pressure, and conveying environment.

　　氣路的首要功能是構建動態密封，平衡系統壓力差。在正壓輸送系統中，供料器轉子與殼體間存在微小間隙，若不采取密封措施，高壓氣流會攜帶物料從間隙外泄。氣路通過在間隙處通入低壓密封氣，形成 “氣封屏障”，阻止物料外溢的同時，避免高壓氣流沖擊轉子。在負壓系統中，氣路則反向通入常壓氣體，防止外界空氣被吸入，確保輸送管道內的真空度穩定。

　　The primary function of an air circuit is to build dynamic seals and balance system pressure differentials. In a positive pressure conveying system, there is a small gap between the feeder rotor and the housing. If no sealing measures are taken, high-pressure airflow will carry materials out of the gap. The air path forms an "air seal barrier" by introducing low-pressure sealing gas into the gap, preventing material overflow while avoiding high-pressure airflow from impacting the rotor. In the negative pressure system, atmospheric pressure gas is introduced in reverse to prevent external air from being sucked in and ensure stable vacuum inside the conveying pipeline.

　　氣路系統對物料流動具有調控作用，可適配不同物理特性的物料。對于易粘結的物料，氣路通過定向噴氣對轉子葉片進行實時清潔，清除附著的物料，避免粘結層增厚導致的輸送量下降。在輕質物料輸送中，氣路可在進料口形成 “氣流緩沖帶”，減緩物料下落速度，防止因沖擊導致的物料破碎。對于高磨蝕性物料，氣路通過在殼體內側形成氣流保護層，減少物料與金屬表面的直接摩擦。

　　The pneumatic system has a regulating effect on material flow and can adapt to materials with different physical properties. For materials that are prone to sticking, the air path uses directional jet to clean the rotor blades in real time, removing attached materials and avoiding a decrease in conveying capacity caused by thickening of the bonding layer. In the transportation of lightweight materials, the air path can form an "airflow buffer zone" at the feed inlet to slow down the material's falling speed and prevent material breakage caused by impact. For highly abrasive materials, the airflow protection layer is formed on the inner side of the shell to reduce direct friction between the material and the metal surface.

　　氣路設計能有效改善設備運行環境，降低維護成本。在粉塵濃度較高的工況中，氣路可通過抽氣裝置將轉子腔體內的懸浮粉塵及時排出，避免粉塵進入軸承等精密部件。針對高溫物料，氣路可通入冷卻氣流，將轉子工作溫度降至 100℃以下，防止密封件因高溫老化。在間歇式輸送場景中，氣路的反吹功能可對殘留物料進行徹底清理，減少物料交叉污染風險。

　　Air circuit design can effectively improve the operating environment of equipment and reduce maintenance costs. In working conditions with high dust concentration, the air path can timely discharge suspended dust in the rotor chamber through an exhaust device, avoiding dust from entering precision components such as bearings. For high-temperature materials, cooling airflow can be introduced into the air path to reduce the operating temperature of the rotor to below 100 ℃, preventing sealing components from aging due to high temperatures. In intermittent conveying scenarios, the blowback function of the air path can thoroughly clean residual materials and reduce the risk of material cross contamination.

　　氣路的結構設計需與工況參數精準匹配。氣源壓力需根據系統壓力差設定，過低無法形成有效密封，過高則會增加能耗。噴氣口位置多分布在轉子兩端面及進料口內側，孔徑為 1-3mm，孔間距 10-15mm，確保氣流覆蓋均勻。氣路控制多采用電磁閥聯動，與供料器轉速同步，避免無效噴氣造成的能源浪費。

　　The structural design of the gas path needs to be accurately matched with the operating parameters. The pressure of the gas source needs to be set according to the system pressure difference. If it is too low, it cannot form an effective seal, and if it is too high, it will increase energy consumption. The nozzle positions are mostly distributed on both ends of the rotor and the inside of the feed port, with a diameter of 1-3mm and a spacing of 10-15mm between holes to ensure uniform airflow coverage. Electromagnetic valve linkage is often used for gas path control, which is synchronized with the speed of the feeder to avoid energy waste caused by ineffective jet injection.

　　不同物料特性對氣路需求存在差異。輸送食品級物料時，氣路需采用無菌氣源；輸送易燃易爆物料，氣路需配置防靜電裝置，并使用惰性氣體替代空氣。在潮濕環境中，氣路需增設排水裝置，避免冷凝水進入物料。

　　There are differences in gas path requirements due to different material characteristics. When transporting food grade materials, a sterile gas source should be used in the air circuit; When transporting flammable and explosive materials, anti-static devices should be installed in the gas circuit, and inert gas should be used instead of air. In humid environments, drainage devices need to be installed in the air circuit to prevent condensed water from entering the materials.

　　氣路系統的維護直接影響供料器性能。需定期清理氣路過濾器，檢查管路連接處密封性，根據物料磨損性更換噴氣嘴。通過氣路與機械結構的協同設計，旋轉供料器可在復雜工況下保持穩定運行，成為物料輸送系統中兼具密封性與調節性的關鍵環節。

　　The maintenance of the pneumatic system directly affects the performance of the feeder. Regularly clean the air path filter, check the sealing of the pipeline connection, and replace the nozzle according to the wear and tear of the material. Through the collaborative design of the gas path and mechanical structure, the rotary feeder can maintain stable operation under complex working conditions, becoming a key link in the material conveying system that combines sealing and regulation.
