在塑料、化工、食品、建材等大宗物料行業,槽罐車作為散裝物料運輸?shù)闹匾ぞ?,承?dān)著從供應商到工廠的高頻物流任務。如何將槽罐車內的物料高效、無塵、安全地輸送至儲存料倉,成為現代工廠物料自動化供應鏈中的關鍵環節。今天帶你全面了解槽罐車加料系統的工藝流程與技術核心。
In the bulk material industries such as plastics, chemicals, food, and building materials, tank trucks serve as important tools for transporting bulk materials and undertake high-frequency logistics tasks from suppliers to factories. How to efficiently, dust-free, and safely transport materials from tank trucks to storage silos has become a key link in the modern factory material automation supply chain. Today, we will take you on a comprehensive understanding of the process flow and technical core of the tank truck feeding system.
01什么是槽罐車加料系統?槽罐車加料系統,指的是將槽罐車內的散裝物料,快速、高效、密閉式輸送至工廠儲存料倉的自動化卸料系統。系統具備多種卸料與輸送工藝,其中氣力卸料及輸送是最常見的方式之一。它是連接外部供應與工廠儲罐的“物流橋梁”,在整個物料供應鏈中占據重要位置。
What is the tank truck feeding system? Tank truck feeding system refers to an automated unloading system that quickly, efficiently, and tightly transports bulk materials from tank trucks to the factory storage bin. The system has multiple unloading and conveying processes, among which pneumatic unloading and conveying are one of the most common methods. It is a "logistics bridge" that connects external supply and factory storage tanks, occupying an important position in the entire material supply chain.
02槽罐車加料系統的標準流程01槽罐車對接槽罐車停靠在指定卸料區域,通過快速接頭與輸料管道對接,避免粉塵外泄。 02物料輸送啟動系統啟動氣力輸送風機,利用氣流推動物料從槽罐車出料口輸送至料倉。03輸送管道物料沿著氣密封閉的輸送管路,快速通過過濾裝置和安全閥,進入目標料倉。04倉頂除塵通過高效倉頂除塵器,及時收集氣流中的粉塵顆粒,確保無塵操作,避免現場污染。05輸送結束系統自動檢測物料輸送狀態,槽罐車卸料完成后自動停機,同時支持缺料報警、系統聯鎖等安全控制。
The standard process for the 02 tank truck feeding system is to dock the tank truck at the designated unloading area and connect it to the conveying pipeline through a quick connector to prevent dust leakage. The 02 material conveying start-up system starts the pneumatic conveying fan, which uses airflow to push the material from the tank truck discharge port to the silo. The material in the 03 conveying pipeline is transported along the airtight closed conveying pipeline, quickly passing through the filtering device and safety valve, and entering the target silo. The dust removal at the top of the 04 warehouse is achieved through an efficient dust collector, which promptly collects dust particles from the airflow to ensure dust-free operation and avoid on-site pollution. The 05 conveying end system automatically detects the material conveying status, and the tank truck automatically stops after unloading is completed. At the same time, it supports safety controls such as material shortage alarm and system interlocking.
03熠生輝槽罐車加料系統的優勢01無塵對接,密閉輸送采用快速插拔對接口,卸料過程全程密封,配備高效除塵器有效防止粉塵飛揚,滿足環保要求。02高效輸送輸送量大,能夠?qū)崿F(xiàn)每小時數噸到幾十噸的輸送效率,大幅縮短卸料時間,尤其適用于單一、大批量物料輸送。03自動化程度高系統配備自動啟停、料位聯鎖、缺料報警等智能控制,操作簡單,可顯著減少人工參與。04多場景適配系統可以根據需求定制,并根據物料特性提供不同尺寸。可根據現場空間設計頂部進料、側面進料,適用于塑料、化工、食品等行業。
03 Advantages of the Yishenghui Tank Truck Feeding System 01 Dust free docking, closed conveying adopts fast insertion and extraction interface, the unloading process is fully sealed, equipped with efficient dust collector to effectively prevent dust from flying, meeting environmental protection requirements. 02 High efficiency conveying has a large conveying capacity and can achieve conveying efficiency of several tons to tens of tons per hour, greatly reducing unloading time, especially suitable for single and large batch material conveying. The 03 highly automated system is equipped with intelligent controls such as automatic start stop, material level interlock, and shortage alarm. It is easy to operate and can significantly reduce manual participation. The 04 multi scenario adaptation system can be customized according to requirements and provide different sizes based on material characteristics. Top feeding and side feeding can be designed according to the on-site space, suitable for industries such as plastics, chemicals, and food.
04應用場景推薦PVC原料自動上料系統鈣粉、滑石粉、大批量粉體氣力輸送系統食品添加劑、面粉、淀粉等槽罐車卸料工藝化工粉體散裝輸送自動化改造項目
04 Recommended application scenarios: PVC raw material automatic feeding system, calcium powder, talc powder, bulk powder pneumatic conveying system, food additives, flour, starch and other tank truck unloading process, chemical powder bulk conveying automation transformation project
